JM-VE01 Vehicle Terminal
JM-VE01 is a vehicle terminal for fleet management and logistics monitoring. Its I/O system, 1-Wire and RS232 interfaces support functions such as fuel level monitoring, temperature monitoring, door status detection, and driver identification.
Everything needed to evaluate this GPS device
Key Features
Supports both LBS and GPS tracking for vehicle monitoring.
Remote fuel and power cutoff helps fleet owners control vehicles.
3G cellular support for communication on GSM-based networks.
Emergency SOS support helps alert emergency contacts.
Dual antenna design supports reliable vehicle terminal operation.
Supports web, app, and SMS-based tracking workflows.
RFID reader support enables driver identification use cases.
Fuel monitoring helps control fuel consumption and reduce operating cost.
Performance & Parameters
- Product Type
- Concox
- Country of Origin
- China
- Dimension (L*W*H)
- 85*65*20
- Weight
- 92g
- Number of Sims
- 1
- Build in Battery
- 500 mAh, Li-Polymer
- Stand By Duration
- 2 days
- Storage logs
- 1000
- Build in Memory
- 32+32Mb
- Working Voltage
- 11-36V
- GPS Chipset
- MTK High Sensitivity chip
- GPS Signal
- L1, 1575.42MHz C/A code
- GPS Channels
- 66
- GPS Fixed Time with AGPS
- Cold Start:<45s Hot start:<1s
- GPS Sensitivity
- Tracking:- 165dBm Capturing:- 14dBm
- Frequency
- GSM:850/900/1800/1900 MHz UMTS:850/900/1900/2100
- GPRS
- Class 12 TCP/IP
- Working Temperature
- -20?to+70?
- Internet Protocol
- 1
Supported Functions
Documents & Manual
Other Supported Devices
Frequently Asked Questions
Which server port does the JM-VE01 use with FleetStack?
The JM-VE01 reports on port 10202. The server host is issued with your FleetStack account credentials. Ports for every other model are listed on the device port list.
What is the JM-VE01 used for?
JM-VE01 is a vehicle terminal for fleet management and logistics monitoring. Its I/O system, 1-Wire and RS232 interfaces support functions such as fuel level monitoring, temperature monitoring, door status detection, and driver identification. It is listed as a vehicle terminal on FleetStack — browse the full range on supported devices.
Which capabilities does the JM-VE01 support?
On the FleetStack capability matrix the JM-VE01 reports: Oil/Power Control (Relay cutoff), SOS. Telemetry feeds GPS tracking, geofencing and the alert center. The documents above carry the manufacturer's full specification.
How do I connect the JM-VE01 to FleetStack?
Point the tracker at your FleetStack server host and port 10202 with the SIM APN set for your network, usually over SMS configuration. The GPS command list carries the SMS and GPRS commands, the video tutorials walk through the platform side, and technical support can help commission a device.
